| Place of Origin: | China |
|---|---|
| Brand Name: | HG or OEM |
| Certification: | ISO9001 |
| Model Number: | GJYXFCH |
| Minimum Order Quantity: | 2KM |
| Packaging Details: | 4KM/Drum |
| Delivery Time: | 5-7 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000KM Per Day |
| Name: | FTTH Drop Cable | Model NO.: | GJYXFCH |
|---|---|---|---|
| Sheath Material: | Length According To Requirement Fiber Cores | Cores: | 2Cores |
| Warranty: | 2Years | Outer Jacket: | PVC,LSZH |
| Highlight: | fiber optic ethernet cable,indoor outdoor fiber cable |
||
2 Cores Armoured Fiber Optic Drop Cable GJYXFCH FTTH Drop Cable
Two core flat drop cable for fiber To The Home (FTTH) application, the cable is constructed with two
single mode fibers protected by dielectric strength member made of steel wire strength member and
LSZH outer jacket for ultraviolet light protection and outdoor use.
It is very light in construction and easy to install, generally used for connecting Main distribution frame
to consolidation point in home, apartment or offices. Industry standard connectors can be used for direct
termination because of standard 250µm fiber size.
| DESCRIPTION | CABLE SPECIFICATION | |
| G652D | G657A | |
| Cladding non-circularity | <1.0% | ≤0.7% |
| Mode eld diameter @ 1310nm | 8.7~9.5µm | 8.4~9.2µm |
| Cladding diameter | 125.0+1.0µm | 125.0+0.7µm |
| Core concentricity error | <0.6µm | <0.5µm |
| Primary coating diameter | 245±7µm | 245±5µm |
| Coating-cladding concentricity error | ≤12.0up | |
| fiber bend radius | >4m | |
| Proof level | >1.5% strain | |
| Fiber type | G652D OR G657A | |
| Tensile load | 80N | |
| Temperature | -20~60°C | |
ANSI/TIA/EIA-598-B Standard Fiber Color Code
Fiber 13 and higher The color code is repeated with added black stripe or dash
Note: Fiber Tube color will be followed with same order.
