| Place of Origin: | China |
|---|---|
| Brand Name: | HG or OEM |
| Certification: | ISO9001 |
| Model Number: | GJFJBV |
| Minimum Order Quantity: | 10KM |
| Packaging Details: | 4KM/Drum |
| Delivery Time: | 5-7 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000KM Per Day |
| Name: | Indoor Duplex Flat Fiber Optic Cable 2Cores LSZH Outer Jacket | Model NO.: | GJFJBV |
|---|---|---|---|
| Sheath Material: | Length According To Requirement Fiber Cores | Cores: | 1- 12 Cores |
| Warranty: | 2Years | Outer Jacket: | LSZH |
| Highlight: | fiber optic network cable,fiber optic ethernet cable |
||
Indoor Duplex Flat Fiber Optic Cable 2Cores LSZH Outer Jacket
Duplex flat optical cable use 900μm tight buffer fiber as optical communication medium, the tight buffer
fiber wrapped with a layer of aramid yarn as strength member units, such unit is extruded with a layer of
LSZH material as inner jacket. Duplex flat optical cable is constructed with two simplex units held together
in an falt LSZH outer jacket. All dielectric structure protect it from electromagnetic influence.
| ITEM | Value |
| Max. Tensile Load (Short Term) | 800N |
| Max. Tensile Load (Long Term) | 300N |
| Max. Crush Load (Short Term) | 1000N/100mm |
| Max Crush Load (Long Term) | 500N/100mm |
| UL Fire Rated | OFNR |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Sheath Material | Standard: LSZH Optional: PVC or other |
ANSI/TIA/EIA-598-B Standard Fiber Color Code
Fiber 13 and higher The color code is repeated with added black stripe or dash
Note: Fiber Tube color will be followed with same order.
