| Place of Origin: | China |
|---|---|
| Brand Name: | HG or OEM |
| Certification: | CE,ROHS, ISO9001 |
| Model Number: | SC APC 2.0mm Fiber Optic Connector |
| Minimum Order Quantity: | 1000pcs |
| Packaging Details: | 10pcs/plastic box |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10K pcs Per Day |
| Products: | Green Color Housing Singlemode SC APC 2.0mm Fiber Optic Connector | Insertion Loss: | IL<0.3db |
|---|---|---|---|
| Model: | SC Apc Fiber Optic Connector 0.9mm | Color: | Blue Color, Beige, Purple, Aqua,Green |
| Application: | Telecommunication | Fiber Type: | SM OM1 OM2 OM3 OM4 |
| Highlight: | fiber cable connector,ftth fast connector |
||
Green Color Housing Singlemode SC APC 2.0mm Fiber Optic Connector
Features
Low insertion loss,high return loss
Excellent Temperature stability
Good repeatability and exchangeability
Excellent mechanical endurance
Strict curing time and temperature control
Strict testing standards and methods for quality
Environment protection (ROHS Compliance)
The fiber optical patch cord can be customized according to customers'specific
requirements (Customized Connector/Length/package...)
100% NEW raw material and well quality control ensure the best life time.
Application
1. Distribution frames
2. Maintenance or emergency restoration of fiber networks
3. Patch panels
4. FTTH
5. Field word
| Product Name | Singlemode SC APC 2.0mm Fiber Optic Pre-assembly Connector |
| Modle Number | Fiber optic SC connector |
| Fiber type | SM OM1 OM2 OM3 OM4 |
| Connector type | SC |
| Insertion Loss | ≤0.3db |
| Reture loss | ≥50db |
| Application | FTTX,CATV Metro,LAN |
| Form of sale | OEM/ODM |
| Use | patch cord,PLC splitter,pigtail |
| Custom Design | Welcome |
| Sample Lead Time | 1day |
| Sample price | As per sample details |
| Certificate | RoHS,SGS,CE |
| Advantage | Best price,best service |
| Features |
1. Pass high&low temperature test 2. 100% raw material 3.steady quality |
| Parameter | Unit | FC,SC,LC | ST,MU | MT-RJ,MPO | |||||||
| SM | MM | SM | MM | SM | MM | ||||||
| PC | UPC | APC | PC | PC | UPC | PC | PC | UPC | PC | ||
| Insertion loss | dB | ≤ 0.3 | ≤ 0.2 | ≤ 0.3 | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | ≤ 0.3 | ≤ 0.2 | ≤ 0.2 |
| Return loss | dB | ≥ 45 | ≥ 50 | ≥ 60 | ≥ 30 | ≥ 50 | ≥ 50 | ≥ 30 | ≥ 45 | ≥ 50 | ≥ 35 |
| Operating wavelength | nm | 1310, 1550 | 1310, 1550 | 1310, 1550 | |||||||
| Exchangeability | dB | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | |||||||
| Vibration | dB | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | |||||||
| Operating temperature | °C | -40~+75 | -40~+75 | -40~+75 | |||||||
| Storage temperature | °C | -40~+85 | -45~+85 | -45~+85 | |||||||
| Cable diameter | mm | φ 3.0, φ 2.0, φ 0.9 | φ 3.0, φ 2.0, φ 0.9 | φ 3.0, φ 2.0, φ 0.9 | |||||||
