Dome 72 Cores Fiber Optic Enclosure Outdoor 5 Round Cable Port Wall Mounting Style

Basic Information
Place of Origin: China
Brand Name: HG or OEM
Certification: iso9001
Model Number: CV014
Minimum Order Quantity: 50pcs
Packaging Details: 1pc/box
Delivery Time: 5-7working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Name: Fiber Optic Enclosure Outdoor Material: PP Materials With UV
Cable Port: 5 Round Port Max. Capacity: 72Fiber
IP: IP68 Warranty: 5 Years
Highlight:

fiber optic splice case

,

fiber optic cable joint box

Dome 72 Cores Fiber Optic Joint Enclosure for Outdoor Cable Joints



Description:

CV014 is widely applied to the splicing, distributing variable optical cables and splitting.



Feature:

1) Adapter: can load 36pcs SC simple adapters or 36pcs LC duplex adapters

2) Splitter: can loaded 1pc PLC splitter 1*8,1*16 or 1*32

3) Splice tray: 3pcs, each 24cores

4) Cable port: 5 cable ports: 4pcs(φ18mm), 1pcs (φ42mm, cable no cutting). All cable ports are mechanical sealing

5) With different size rubber gasket for simplex, FTTH drop cable entry/exit

6) Waterproof: IP68

7) Wall-mounting, aerial hanger and pole holding

8) Material: high impact resistance PP materials with UV



Specification:

Model Capacity Dimension Splice tray Weight
CV014

72 fibers

Max. 144 fibers

φ182.5 x 521.1 mm

3pcs, each 24 fibers

If without adapter panel, Max.6pcs

4.0 kgs
